CAT6 LAN 4 PR EXT BK B3HM
CAT6 LAN 4 PR EXT BK B3HM
Bare copper conductor, polyolefin insulated, twisted pairs, gel filled, black polyethylene outer sheath.
Read more- Nexans ref. : JCAT6FPA3
- Country ref. : JCAT6FPA3
- EAN : 9319215386603
Description
Description
Application
Designed for use in high speed data/comms networks. Manufactured for compatibility with the RJ Type connector.
New Free Section - 101737
Characteristics
Characteristics
Construction characteristics
Construction characteristics
Sheath colour
Black
Dimensional characteristics
Dimensional characteristics
Approximate weight
4.15 kg/100m
Cable Diameter
6.3 mm
Conductor cross-section
0.22 mm²
Number of pairs
4
Stranding (No./mm)
1/0.54
Electrical characteristics
Electrical characteristics
Max. DC resistance of the conductor at 20°C
93.8 Ohm/km
Nominal impedance
100 Ohm
Nominal mutual capacitance
51 pF/m
Mechanical characteristics
Mechanical characteristics
Maximum installation tension
110 N
Usage characteristics
Usage characteristics
Installation temperature, range
0 ... 50 °C
Minimum Bend Radius - During Installation (under Tension)
50 mm
Minimum Bend Radius - Installed
25 mm
Operating temperature, range
-20 ... 60 °C
